Specifications
Interface: USB, bus powered device
Current Input: max. 150 mA
Smart Card Interface
Reads and writes all ISO 7816 cards supports T=0, T=1, I²C (S=8), 2 wire (S=10), 3 wire (S=9)
Card Connecting Unit: approx. 100,000 insertions
Smart Card Speed: 412,903 bps
Clock Frequency Smartcard: 4.8 MHz
Sensor Resolution: 250 dpi
Cable Length: approx. 1.75 m
Number of Keys
104 = EU Layout with Windows™ keys
105 = US Layout with Windows™ keys
Weight
approx. 2.62 lbs (without packaging)
approx. 3.30 lbs (with packaging)
Dimensions
approx. 17.9 x 7.7 x 2.1 (keyboard)
approx. 19.4 x 10.0 x 2.3 (packaging)
Keyswitch Lifetime: > 20 million operations
System Requirements: USB Connection
Insertion Cycles
approx. 100,000
Smart Card Speed:
412,903 bps
Smart Card Clock: 4.8 MHz
Storage Temperature: -20°C to 60°C
Operating Temperature: 0°C to 50°C
Agency Approvals
FCC, GS, CE, c-tick, GHOST-R, VCCI Microsoft WHQL Windows™ 2000, XP
Features
An advanced performance line keyboard with an integrated Smart Card Reader and biometric scanner. Light gray housing, smart card reader, fingerprint sensor.
Key Features
- USB keyboard with fingerprint sensor and PC/SC smart card reader
- AuthenTec AES CMOS Fingerprint Sensor with TruePrint® Technology
- CardMan 3121-compatible Smart card reader
