The Cherry G84-4700LPBUS-2 is a Compact Keypad Featuring ML Technology with Gold Crosspoint Contacts.For pricing and availability, call our Sales Department at 800-459-7931 (or 480-813-3100) or use our convenient contact form.
Price: $0.00
|
Specifications
Features
Setup
Use
Related Products
Specifications Power Supply: 3.3-5.0 VDC ± 10% SELV
Current Input: typ. 50 mA
Connecting Cable: approx. 1.75 m long
Weight: approx. 260 g
Storage Temperature: -20°C to 60°C
Operating Temperature: 0°C to 50°C
Dimensions of Housing: 90 x 132 x 36 mm
Cherry MX Switches with Gold Crosspoint Contacts
Actuation Characteristics: Soft contact Features Black, PS/2 Interface, 21 programmable keys, 4 relegendable, ML keyswitches, second PS/2 port for keyboard Main Applications - Numerical input
- Control systems
- Frequent entry of numbers
- Extension for notebook computer
Key Features - Programmable 21-key numeric layout
- Equally suitable for left-handed and right-handed users
- Low space requirements
- All keys can be user-defined with up to 24 characters per key
- 4 additional user-programmable function keys, can be labeled individually
- Digits can be entered independently of the status of the Num Lock in the system (operation on notebook PC)
- Variable decimal separator [.], [,], [00], or [000]
- External standard keyboard can be connected
- Matches design of Cherry keyboards G84-4100
- Uses mechanical keys from our ML series with high-precision key action; small physical dimensions:
- Reliability: MTBF: 550,000 hours
|
